POWERTRAIN SYSTEM
The all-new powertrain puts the driver first. Even with class-leading specs like 75-degree DOHC V-6, twin-turbo charging, 3 motors and 9-speed DCT, the NSX is most remarkable for the human connection.
IT'S IN THE DNA | NSX For Sale
The NSX was engineered to be the absolute perfect balance of power and handling, form and function, sport and luxury. The same innovations that went into creating the NSX can be found across the entire Acura lineup
Reserve your NSX today
We have a new NSX come in every month! There are already a limited number of NSX's available to consumers and after the Super Bowl coverage the market is even busier. Make sure you reserve your NSX here at Park Place Acura today. See what NSX we have available now.
See our current NSX AvailabilityLearn More About NSX
Aerodynamics of the NSX | Plano, TX
This car breathes. As it inhales and exhales, air flows over and all through the NSX with a revolutionary system that creates down-force without disrupting the design. While the NSX stays cool with thermal dynamics, it will take your breath away.
Reserve your NSX
* Indicates a required field
By providing your information or texting and calling us directly, you agree to receive manual, automated and pre-recorded texts, emails, and phone calls from Park Place Acura, its parent company Asbury Automotive, and all affiliates including our manufacturer and distributor partners. These informational and marketing communications may be powered by Artificial Intelligence, tailored to give you the most guest-centric experience possible. Messages and data rates may apply.
We offer a variety of reasonable ways to opt out or unsubscribe from all communications including an opt-out form on our website. You can find this form in the navigation under the “About Us” section labeled “Unsubscribe”, at the bottom of the homepage, or via our privacy policy page.
For more information, please visit our website privacy policy page or email us at privacy@asburyauto.com.
Contact
HAND-BUILT ENGINE
Perfect parts are staged one-by-one in sequence. It takes five hours to build a single engine assembled by one of six master builders. Precision is part of the assembly process. Human touch is part of the DNA.
HUB OF CRAFTSMANSHIP
Acura's Performance Manufacturing Center is where the next-generation NSX comes to life. Constructed entirely in-house, the pride that is in each detail is resounding and reassuring.
NSX Technical Specifications | New NSX Inventory
NSX Power Unit
| Sport Hybrid SH-AWD Power Unit | Front wheels: mechanically independent from rear power unit components, two electric motors (Twin Motor Unit); Rear wheels: Twin-turbocharged V-6 gasoline engine with one Direct Drive Motor and 9-speed DCT |
| Maximum Total System Power | 573 hp |
| Approx. Top Speed | 191 mph |
NSX Engine
| Type | Twin-turbocharged DOHC V6 |
| Layout | Longitudinally mid-mounted |
| Displacement | 3493 cc |
| Power - SAE Net | 500 hp @ 6500 - 7500 rpm |
| Torque (Nm) | 406 lb.-ft. (550) @ 2000 - 6000 rpm |
| Maximum Engine Speed | 7500 rpm |
| Power Output Per Lite | 143 hp/liter |
| Bore and Stroke | 3.6 in. x 3.5 in. |
| Compression ratio | 10.0:1 |
| Valve Train | 24 Valve, IN/EX VTC, chain-driven camshafts |
| Intake Valve Construction | Forged steel |
| Exhaust Valve Construction | Forged steel, sodium-filled |
| Valve Angle | 30 degrees (include angle) |
| Cylinder Block and Head Material | Aluminum alloy |
| Cylinder Bore Lining | Plasma transferred wire arc thermal spray |
| Cylinder Bank Angle | 75 degrees |
| Crankshaft Construction | Forged steel |
| Piston Construction | Cast aluminum with integrated cooling channel |
| Connecting Rod Construction | Forged steel, dowel pin |
| Fuel Injection | Direct and port |
| Throttle Control | Drive-by-Wire throttle system |
| Fuel Requirement | Premium unleaded |
| Lubrication | Dry sump system with 6-rotor scavenge pump |
| Oil Type | Synthetic 0W-40 |
| Cooling system | Liquid and oil cooling |
| Exhaust System Layout | Dual catalytic converter, dual path per bank |
Twin Turbochargers in the NSX | Plano
| Turbocharger Type | Single vane |
| Maximum Boost Pressure | 105 kPa (1.05 bar) |
| Turbine Construction | Inconel |
| Wastegate Control | Electrical |
| Recirculation Valves | Air bypass type |
| Intercooler Dimensions | Width 232.2 mm; Height 382 mm; Thickness 64 mm |
Rear Direct Drive Motor
| Type | Water-cooled motor/generator |
| Layout | Direct drive situated between engine & transmission; Crankshaft output shaft-attached permanent magnet rotor & in-engine body-copper windings |
| Horsepower @ rpm | 47 @ 3000 |
| Torque @ rpm | 109 lb.-ft. @ 500 - 2000 |
Transmission & Rear Axle
| Type | 9-Speed Dual Clutch Transmission (9DCT) |
| 1st Gear ratio | 3.838 |
| 2nd | 2.433 |
| 3rd | 1.778 |
| 4th | 1.428 |
| 5th | 1.211 |
| 6th | 1.038 |
| 7th | 0.881 |
| 8th | 0.747 |
| 9th | 0.634 |
| Reverse | 2.395 |
| Rear Axle Ratio | 3.583 |
| Limited Slip Differential - Wet Multi Plate | Torque bias ratio: Drive 2.0, Coast 2.6, 30N-m Pre load |
Front Twin Motor Unit (TMU)
| Type | Twin traction motor/generator |
| Layout | Independent, twin motors packaged back-to-back with a single clutch, gear-linked system |
| Horsepower @ rpm | 36 + 36 @ 4000 |
| Torque @ rpm | 54 +54 lb.-ft. @ 0 - 2000 |
Additional Power Unit Controls
| Integrated Dynamics System | Four-mode system: Quiet, Sport, Sport+, Track |
| Hill Start Assist | |
| Idle-Stop System |
Body / Suspension / Chasis
| Chassis Type | Aluminum-intensive, Multi Material |
| Body/Frame Construction | Multi-material (primarily aluminum) space frame with aluminum and low-density SMC outer panels, and cast aluminum suspension mounting points |
| Ablation Cast Aluminum Node | Complex high performance aluminum castings for crush zones;World's first automotive application |
| Corrosion Pre-Treatment | Zirconium pre-treat material; Environmentally friendly |
| A-Pillar Structure | 3-D Bent and Quenched ultra-high-strength steel (1500 Mpa);World's first application |
| Floor Panel | Carbon fiber core |
| Front Suspension Type | Double-wishbone, double lower control arm; aluminum |
| Front Dampers | Active Gen III magnetorheological coilovers |
| Front Stabilizer Bar | Hollow steel, 1.04 in. diameter x 0.13 in. wall thickness |
| Rear Suspension Type | Multi-link; aluminum |
| Rear Dampers | Active Gen III magnetorheological coilovers |
| Rear Stabilizer Bar | Hollow steel; 0.98 in. diameter x 0.12 in. wall thickness |
| Front Brake Calipers | Brembo 6-piston Aluminum Monoblock |
| Front Brake Rotor Type | Base: 2-Pc Floating Iron Disks w/ Aluminum center Option: 2-Pc Floating Carbon Ceramic Disks w/ Aluminum center |
| Front Brake Rotor Size | Iron: 14.5 in. diameter x 1.3 in. thick Carbon ceramic: 15 in. diameter x 1.3 in. thick |
| Rear Brake Calipers | Brembo 4-piston Aluminum Monoblock |
| Rear Brake Rotor Type | Base: 2-Pc Floating Iron Disks w/ Aluminum center Option: 2-Pc Floating Carbon Ceramic Disks w/ Aluminum center |
| Rear Brake Rotor Size | 14.2 in. dia. X 1.3 in. thick (both iron and carbon ceramic) |
| Steering Type | Variable ratio rack & pinion; Dual-pinion EPS |
| Steering Wheel Turns, Lock-to-Lock | 1.91 |
| Steering Ratio | Variable progressive; Range: 12.9:1 (on center) to 11.07:1 |
| Turning diameter, Curb-to-Curb | 39.7 ft. |
| Front Wheels | 19x8.5J Forged Aluminum |
| Front Tires | 245/35ZR19 93Y SOT |
| Rear Wheels | 20x11J Forged Aluminum |
| Rear Tires | 305/30ZR20 103Y SOT |
| Spare Tire | Tire Repair Kit |
| Fuel Tank Layout | Twin fuel tanks mounted between the engine and IPU |
Exterior Dimensions
| Wheelbase | 103.5 in. |
| Length | 176 in. |
| Height | 47.8 in. |
| Width | 87.3 in. |
| Track (front/rear) | 65.2 in. / 63.7 in. |
| Ground Clearance | 3.7 in. |
| Approach/Departure Angles | 9.2° / 12.9° |
Capacities and Weights
| Fuel Tank Capacity | 15.6 gal |
| Curb Weight (without Options) | 3,803 lbs. |
| Weight Distribution (front / rear without options) | 42% / 58% |
Interior Dimensions
| Seating Capacity | 2 |
| Headroom | 38.3 in. |
| Legroom | 42.8 in. |
| Shoulder Room | 57.6 in. |
| Hip Room | 54.5 in. |
| Cargo Volume (behind rear engine compartment) | 3.9 ft3 |
| Passenger Volume | 44.0 ft3 |
EPA Mileage Ratings Fuel
| Fuel Type | Premium |
Active Safety Features
| Vehicle Stability Assist™ (VSA®) with Traction Control7 | |
| Anti-Lock Braking System (ABS) | |
| Electronic Brake Distribution (EBD) | |
| Multi-Angle Rearview Camera with Dynamic Guidelines | |
| Tire Pressure Monitoring System (TPMS) with Location and Pressure Indicators | |
| Brake Assist | |
| LED Daytime Running Lights (DRL) |
Passive Safety Features
| Single-Stage Driver, Dual-Stage Passenger, Multiple-Threshold Front Airbags (SRS) | |
| SmartVent®Front Side Airbags | |
| One-Row Side Curtain Airbags with Rollover Sensor | |
| 3-Point Seat Belts with Automatic Tensioning System | |
| Upper Tether for Child Seat on Passenger-Side | |
| Driver's and Passenger's Seat-Belt Reminder |
Driver Assistive Features
| Cruise Control | |
| Auto High-Beam Headlights | |
| Corner and Backup Sensors |
Exterior Features
| Flush-mounted automatic power pop-out door handles | Auto pop out upon approach with keyless entry fob |
| Capless Fuel Filler | |
| Radio Antenna | Integrated front windshield type |
| Acoustic Front Windshield | |
| Side Windows | |
| Acoustic Glass Rear Cabin Window | |
| LED Brake Lights | |
| Variable Intermittent Wipers | |
| Remote keyless Smart Entry system | |
| Side Mirrors | Body-colored power heated with reverse auto tilt-down and integrated LED turn indicators; Optional memory feature |
| Security System | |
| Headlamps | Acura Jewel Eye™ LED type with Auto-On/Off |
| Body Panels | Composite |
| Roof Panel | Aluminum or optional exposed-weave carbon fiber |
Interior & Comfort / Convenience
| Beverage Holder | Two-cup holder unit that slides into a slot in the center console on passenger side |
| Automatic Air Conditioning with air filtration system | |
| Push Button Start | |
| Active Noise Control™ (ANC) | |
| Active Sound Control (ASC) | |
| Power Windows with Auto-Up/Down | |
| Power Door Locks | |
| Cruise Control | |
| Tilt and Telescopic Steering Column (manual) | |
| Center Console Storage | Multi-functional storage system |
| Lockable Glove Compartment | |
| 12-Volt Power Outlet | |
| Power Remote Fuel Filler Door Release | |
| Rear Engine Compartment Window Defroster w/ Timer | |
| Cargo Area Light | |
| Cargo Area Tie-Down Anchors (4 Total) | Optional accessory cargo net |
| Illuminated Steering Wheel-Mounted Controls | Cruise / Audio / Phone / Display Audio |
| Dual-Zone Automatic Climate Control System with Humidity Control and Air Filtration | |
| HomeLink®Remote System | |
| Frameless Automatic-Dimming Rearview Mirror | |
| Leather-Wrapped Steering Wheel | Available carbon fiber trim |
| LED Interior Ambient Lighting | |
| Leather--Trimmed Instrument Panel | |
| Leather-Trimmed Door Panels | |
| Alcantara Roof Lining |
Seating
| Seats | Perforated leather and Alcantara-trimmed with manual adjusters; Optional 4-way power adjusters |
| Seat Leather | Milano leather standard; Semi-aniline leather option |
| Heated Seats |
Audio & Connectivity
| 7-Inch Display Audio with High-Resolution WVGA (800x480) Electrostatic Touch-Screen and Customizable Feature Settings | |
| Audio System | Standard Audio system: 8 speakers, including subwoofer Optional ELS Studio Premium Audio system: 9 speakers, including subwoofer |
| Bluetooth®HandsFreeLink® | |
| Bluetooth®Streaming Audio | |
| MP3/Auxiliary Input Jack | MP3/Auxiliary Input Jack |
| USB Audio Interface | 2 USB ports in car (In glove box) 1.0 Amp charge capability & USB connection without Apple CarPlay™ & Android Auto connectivity (In console box) 1.5 Amp charge capability & USB connection with Apple CarPlay™ & Android Auto connectivity |
| AcuraLink®Next Generation | |
| SMS Text Message Function | |
| SiriusXM®Radio | Option |
| Pandora®Compatibility | |
| Acura Satellite-Linked Navigation System™ with Voice Recognition and Honda HD Digital Traffic | |
| HDMI Interface | In rear console |
| HD Radio™ | |
| Siri Eyes Free | |
| Android Auto | |
| Apple CarPlay™ |
Instrumentation
| Digital Speedometer | TFT Screen |
| Tachometer | TFT Screen |
| Coolant Temperature Indicator | Analog gauge |
| Fuel Level Indicator | Analog gauge |
Dynamic TFT Gauge Cluster
| 4.2-Inch Color TFT Screen | 8-Inch Color TFT Screen |
| Integrated Dynamics System-linked Dynamic Meters | Meter Graphics Color change: Quiet-Blue; Sport-White; Sport+ and Track-Red |
| Average Fuel Economy Indicator | |
| Gear Position Indicator | |
| Instant Fuel Economy Indicator | |
| Miles-to-Empty Indicator | |
| Odometer and Trip Meters (2) | |
| Tire Pressure Monitoring System (TPMS) with Tire Fill Assist and Location and Pressure Indicators | |
| Exterior Temperature Indicator | |
| Compass | |
| Turn-By-Turn Directions | |
| Customizable Feature Settings |
Colors
Exterior
| Valencia Red Pearl | |
| Nouvelle Blue Pearl | |
| Casino White Pearl | |
| Source Silver Metallic | |
| Nord Gray Metallic | |
| Curva Red | |
| 130R White | |
| Berlina Black |
Interior
| Ebony | All exterior colors are available with all interior colors |
| Saddle | All exterior colors are available with all interior colors |
| Red | All exterior colors are available with all interior colors |
| Seacoast | All exterior colors are available with all interior colors |
Acura NSX Factory Options
| Carbon Fiber Exterior Sport Package | Carbon fiber front spoiler, side sills, rear diffuser; Dark chrome exhaust finisher |
| Carbon Fiber Engine Cover | |
| Carbon Fiber Roof | |
| Carbon Ceramic Brake Rotors | Includes choice of black, red or silver brake calipers |
| Carbon Fiber Rear Spoiler | |
| Exclusive Interwoven Aluminum Alloy Wheels | Choice of machined, painted or polished finish |
| Technology Package - ELS Studio Audio System | Includes 9 speakers, Navigation, AcuraLink, front and rear parking sensors |
| Technology Package - ELS Studio Audio with XM Satellite Radio | Same as above and adds XM Satellite radio |
| Interior Carbon Fiber Sport Package | Includes carbon fiber meter visor and steering wheel garnish, aluminum foot rest and sport pedals |
| Alcantara Headliner | Black |
